Full length support - prevents breakage and stays tight
All flanges have rounded edges - eliminating ball damage at this point
¼” steel flanges are angled to guide ball directly under lift
Support strap - full welds to flanges plus ¼” steel equals strongest ever
¼” support ear prevents breakage and gets strapped to its mate for additional strength
Part #DURO
Must be ordered as a set. Kit includes both rings and installation hardware
CALL 1-877-235-8300 TO ORDER
The Worlds First Hingeless Front Roller
Part # LL 300-301
·No links or hinges to wear out·True tracking with any carpet·Carpet will always track toward the ball exit·Extends carpet life dramatically·Automatically actuates to each carpet drift·Even old carpets with trimmed edges will track toward the exit·Cuts labor and parts cost·Use your existing front roller body·Comes with everything you need to covert an odd or even machine
How It WorksOur roller goes around and back and forth without the need for hinges or bearings. We can do this because we use a material called Nylube (oil impregnated nylon). It’s a specialized industrial type that is so strong it outwears steel. The roller looks like the old style on the outside but is very different inside. Instead of hinges there is a solid piece that runs from one kickback to the other. There are two solid steel pieces that sit in the bearing supports instead of bearings. This center section doesn’t move at all.Each end of the roller has a Nylube core with a machined end that inclines for 90 degrees of its rotation. The incline acts as a cam, and it’s the cam that pushes the roller away from the exit as the carpet drifts. The stationary core has a cam follower on it. The carpet is allowed to drift toward the exit until the Nylube cam contacts the cam follower, then gets pushed away. It’s that simple and doesn’t rely on the carpet pushing against the edge of the roller to make it work. That’s a tremendous advantage for extended carpet life.
New PBL ball Lift belt and accelerator totally eliminates ball calls Better yet it has a 10 year prorated warranty Buy separately or togetherThe beltThe booster belt is super strong to prevent stretching and has three small humps lined up on each side of the belt 180 degrees apart. As your PBL lift arm raises the humps act as three additional actuations in rapid succession. This is designed to get the ball up and onto the up rails under any oil conditions. The ball acceleratorThe boosterball accelerator prevents the ball lift belt from concaving as the ball rises preventing slipping on the up rails by keeping extra and constant pressure on the ball. It works like nothing else possibly can as it prevents oily up rails from slipping. Using both togetherThe belt gets the ball onto the up rails and the accelerator keeps the ball from slipping. Working together creates a dynamic function that’s unstoppable. With the accelerator installed the belt humps gives a much extra pushing action onto the ball because the belt can’t concave. Super oily pro shot conditions – no problem. Worn and oil soaked up rails – no problem. Miss aligned machines that never seem to work right – no problem. Slimy house balls that give havoc – no problem.
Click on the right to see them working together
Has run in centers maintenance free for decades. Huge parts and labor savings. Call for references.
Full length support - prevents breakage and stays tight
All flanges have rounded edges - eliminating ball damage at this point
¼” steel flanges are angled to guide ball directly under lift
Support strap - full welds to flanges plus ¼” steel equals strongest ever
¼” support ear prevents breakage and gets strapped to its mate for additional strength
Part #DURO
Must be ordered as a set. Kit includes both rings and installation hardware
CALL1-877-235-8300TO ORDER
THE DURO-RINGThe Toughest Door Weldment Ring EverBACKED BY A 10 YEAR WARRANTY
The Worlds First Hingeless Front Roller
Part # LL 300-301
·No links or hinges to wear out·True tracking with any carpet·Carpet will always track toward the ball exit·Extends carpet life dramatically·Automatically actuates to each carpet drift·Even old carpets with trimmed edges will track toward the exit·Cuts labor and parts cost·Use your existing front roller body·Comes with everything you need to covert an odd or even machine
How It WorksOur new roller goes around and back and forth without the need for hinges or bearings. We can do this because we use a material called Nylube (oil impregnated nylon). It’s a specialized industrial type that is so strong it outwears steel.The roller looks like the old style on the outside but is very different inside. Instead of hinges there is a solid piece that runs from one kickback to the other. There are two solid steel pieces that sit in the bearing supports instead of bearings. This center section doesn’t move at all.Each end of the roller has a Nylube core with a machined end that inclines for 90 degrees of its rotation. The incline acts as a cam, and it’s the cam that pushes the roller away from the exit as the carpet drifts. The stationary core has a cam follower on it. The carpet is allowed to drift toward the exit until the Nylube cam contacts the cam follower, then gets pushed away. It’s that simple and doesn’t rely on the carpet pushing against the edge of the roller to make it work. That’s a tremendous advantage for extended carpet life.
